Alpine X-W12D4 12" Subwoofer

Alpine

$599.00

Diaphram

Material: Kevlar Rohacell® Layered Composite
Design: 1-Piece Parabolic with Vented Force Transfer Assembly
Surround
Material: Injection Molded Santoprene®
Design: High Amplitude Multi-Roll (HAMR Surround)
Spider
Material: Nomex®
Design: Dual Progressive with Integrated Tinsel Leads
Voice Coil
Material: Aluminum Former
Design: 2.6″ (65.5mm) Voice Coil
Motor Structure
Pole Geometry: Airflow Optimized Dual Flare Pole Vent
Configuration: Triple-Stacked High Power Strontium Ferrite Magnets
Frame
Material: Cast Aluminum
Terminals
Layout: One Side
Design: 8mm² Insert Terminals with Series/Parallel Jumper Plug
Tinsel Leads
Design: Reinforced Layer Spider Integration
Gasket
Design: Grille/Trim Ring Twist-Lock System

Power Handling
Power Range: 650W-900W
RMS Power Handling: 900W
Peak Power Handling: 2700W
Dimensions
Mounting Depth: 7-1/4′′ (184mm)
Mounting Diameter: 11-1/16′′ (281mm)
General
Frequency Response: 22Hz-200Hz

Thiele-Small Parameters
Sensitivity (1W/1m) – SPL
DC Resistance – Re
Inductance – Le
Free Air Resonance – Fs
Equivalent Stiffness – Vas
Mechanical Q – Qms
Electrical Q – Qes
Total Q – Qts
Cone Area – Sd
Linear Excursion – Xmax (1-way)
Mechanical Travel – Xmech (P-P)

SKU: 10095 TAGS: alpine, x type, Subwoofer, 12" subwoofer, 12 inch
