Alpine CDE-170e



Out of stock

Alpine CDE-170E

CD Receiver with USB

Alpine’s all-new CDE-170E is specially designed for listening to CD’s and digital music files on USB. The sound tuning capabilities include a 3-Band Parametric EQ and high pass and low pass filters for easy, fully customizable sound tuning. The 50 Watts x 4 amplifier produces clear and powerful sound, plus dual PreOuts allow connection to external amplifiers for further expansion of your system.

Enjoy all your favourite songs through the built-in CD player, or connect a flash drive to the convenient front USB port for endless music playback. The CDE-170E supports the latest Android Open Accessory 2.2 (AOA 2.0) technology, providing full control of audio on an Android smartphone via USB.

Front Auxiliary and USB Connection
The Front Auxiliary and USB connection provides playback of virtually any portable audio device. The Front USB lets you playback music files stored on a USB memory devices. The 3.5mm Auxiliary Jack on the front makes a simple connection to your portable player to playback through your Alpine System.

2 Preouts
The two sets of RCA PreOut lets you add amplifiers, speakers and subwoofers to the system to enjoy an amazing high-performance sound system. The selectable subwoofer control allows you to adjust the bass level intensity to exactly how you like it.

24 bit D/A converter
To ensure only the best sound quality, premium Alpine head units use high-resolution Burr Brown 24-Bit Digital-to-Analogue conversion. The 24-Bit DAC decodes the digital signal into amazing sound reproduction, allowing for an incredible Signal to Noise ratio of 105dB

50 Watts x 4 Built-in Amplifier
This high quality head unit delivers exceptional clean sound from its built-in high-power 50 Watts x 4 amplifier. Perfectly matched to Alpine speakers, you will enjoy brilliant sound quality.

Parametric Equaliser
A divider separates the audio signal into two or more frequency bands to feed different amplifiers or speakers.

Bass Engine SQ
The BASS button takes you directly to Alpine’s advanced bass level adjustment function. As you choose one of the five levels, it automatically adjusts frequency cutoff, Q factor and subwoofer level for optimum sound quality. Choose from Standard, Punch, Rich, Mid Bass or Low Bass.

FLAC High Resolution Music Playback
FLAC (Free Lossless Audio Codec) is a lossless compression format. Digital audio compressed by FLAC's algorithm can typically be reduced to 50-60% of its original size and decompressed to an identical copy of the original audio data without any data loss, allowing for superior sound quality.

Radio Data System
RDS is a communications protocol which sends small amounts of digital information to your head unit. This allows you to view extra radio information, including station name and now playing track/artist information.

Play your compressed music files. When you purchase music from the Internet and burn it onto CDs, you naturally want to play it in your car. Select Alpine head units are fully compatible and are ready to handle all your compressed music files: AAC, MP3 and WMA. Plus, with Alpine’s Built-in high power amps and Alpine speakers, they’ll sound better than ever.


50W x 4 High Power Amp
FM/AM Radio
Front AUX
Front USB
CD/MP3/WMA Playback
3 Band Parametric EQ
High Pass & Low Pass Filters
2 Preouts
Bass Engine SQ
AOA 2.0 (Android Open Accessory
24-Bit DAC
Detachable Face Plate



Tuning Range 87.5 ~ 108.0 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 μV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531 ~ 1,602 kHz
Sensitivity (IEC Standard) 22.5 μV/27 dB
Frequency Response 5 ~ 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS)
Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
USB requirements USB 1.1/2.0
Max. Power Consumption 1,000 mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG AUDIO Layer-3
WMA Decoding Windows Media™ Audio
Wave length 795 nm
Laser power CLASS I
Power Requirement 14.4 V DC (11 ~ 16 V allowable)
Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass ±14 dB at 100 Hz
Mid ±14 dB at 1 kHz
Treble ±14 dB at 10 kHz
Loudness 10 dB at 100 Hz
Width 178 mm (7″)
Height 50 mm (2″)
Depth 160.5 mm (6–5/16″)
Width 170 mm (6–3/4″)
Height 46 mm (1–13/16″)
Depth 25 mm (1″)

SKU: 10000-47 TAGS: 2 preouts, mp3
