GME TX3350UVP TX3350 Ultimate Value Pack

Super Compact UHF CB Radio with LCD SoundPath™ Speaker mic

The TX3350 is an 80 channel, feature packed super compact UHF CB radio with the new SoundPath™ full function LCD Speaker Microphone.
The challenge was to create a unique solution that allowed a full function LCD Microphone that could house a built in speaker with clear audio all within a compact and ergonomic design.  SoundPath™ diverts the audio through a unique convex path around the microphone bollard, whilst maintaining the compact size.
The TX3350 combines the unique combination of space saving benefits of a super compact size radio and full function speaker microphone all in the palm of your hand. The radio can now be discretely installed in almost any location within a vehicle and without the need for extension speakers.

Product Specifications

GENERAL
Compliant Specification
Meets AS/NZS 4365 for radio communications equipment in the UHF citizen and personal radio service.

Frequency Range TX
476.425 – 477.4125 MHz

Number of Channels
80 UHF CB

Channel Spacing
12.5 kHz

Operation Mode
simplex channels 1-80, Semi Duplex channels 1‑8, 41-48

Scanning Speed
20 channels per second

Antenna Impedance
50 Ohms nominal

Nominal Battery Voltage
13.8 volts DC

Operating Voltage Range
10-15 volts DC

Overvoltage Protection
25 volts DC max At 18 volts DC the RF power is reduced, and the words ‘Hi DC’ flash.

Overcurrent Protection
In-line 2A Fuse

Frequency stability
±2.5 PPM

Modulation
FM

TRANSMITTER
RF Output
5.0 watts max

Maximum Deviation
< ± 2.5 kHz at + 20 dB limiting

Transmit Frequency Response
+6 dB per octave, 300 Hz to 3 kHz + 1-3 dB

Current Consumption
1.5 amps with 50 Ohms termination

RECEIVER
Intermediate Frequencies
1st - 21.54, MHz 2nd - 450 kHz

Sensitivity
- 123 dBm for 12 dB SINAD unweighted

Selectivity
- 6 dB at + 3.5 kHz, ‑ 60 dB at ± 12.5 kHz

Intermodulation Immunity
73 dB

Blocking Immunity
100 dB

Spurious Response Immunity
70 dB

Audio Output Power
3 watts average into 4 Ohms

Current consumption
< 180 mA muted 600 mA @ max. A.F output

Receive Frequency
‑6 dB/Octave de‑emphasis, 300 Hz to 3 kHz + 1-3 dB

Conducted Spurious Emission
< - 57 dBm

MECHANICAL SPECIFICATIONS
Dimensions
102 (W) x 87 (D) x 23 (H) mm

Weight
158 grams

Product Details

Powered by Pure Sound DSP engine
Full spectrum backlit LCD microphone with Soundpath speaker
User selectable open and group scan
User adjustable squelch
User selectable duplex channels
User selectable priority channel
104 in-built DCS codes
50 in-built CTCSS codes
5 digit selcall with quiet mode
Five year warranty
Australian design and manufacture

In the Box:
TX3350 Radio Unit
LCD Speaker Microphone
AE4018K3 Rugged Antenna Kit
AE4002 Low Gain Replacement Antenna Whip
MB407SS Universal "Z" Bonnet/Boot Antenna Mount
MB024SS Universal Bull Bar Antenna Mount
Microphone Clip
Screw Pack
DC Lead
Mounting Cradle
