DD Audio M1D Mono Block

DD Audio Amplifier 1700w x 1 @ 1 Ohm

Overview

The M1 is one of our most popular amps of all time, and it is now entering its 5th generation. The M1d is the perfect amp for a myriad of applications, delivering over 1200 Watts of true RMS power at 12 Volts, 1700 Watts continuous at 14.4 Volts, and over 2500 Watts dynamic power. The compact layout uses our LV type twin power supply, which keeps the chassis small and the power big while allowing for a plethora of mounting options. 0 Gauge power connections and through bolted RCAs provided high-end features at an affordable price.

For installation ease, and upgradeability the M1d features Strap mode. When using Strap Mode you’re able to have two M1d in an install and control the Strapped amplifier level settings from the Main amp. You’ll also be able to use a single remote gain to control both amps.

The M1d also comes with the VM-RMT remote control. The VM-RMT is a mini amplifier diagnostic center that’s able to mount within arms reach for real-time performance monitoring and adjustments. From this remote, you have fine gain control, amplifier input voltage monitoring, and output clipping monitoring.

Specifications

Test Voltage 12 / 14.4

Channels 1

Cont Wattage @ 4ohm N/A

Cont Wattage @ 2ohm N/A

Cont Wattage @ 1ohm 1,200x1@12V / 1,700x1@14.4V

Dynamic Wattage 2,500x1

Max Current Draw – Amperage 170

S/N Ratio >100dB

THD <0.2%

Input Voltage Sensitivity 8 - 0.2

Pass-Through Output Yes

Remote Subwoofer Control Yes

Power Wire Guage In 1 x 0

Speaker Wire Gauge Out 10

Dimensions: in 13.77 x 6.88 x 2.14

Dimensions: mm 350 x 175 x 54.5
